INSULATING GLASS

Overview

Insulating glass is a new building material with good heat insulation, sound insulation, beautiful and applicable, and can reduce the dead weight of buildings. It is a high-efficiency sound insulation glass made of two (or three) pieces of glass, using a high-strength and high air tightness composite adhesive, and bonding the glass sheet with an aluminum alloy frame containing a desiccant. Insulating glass has many advantages over ordinary double-layer glass, so it has been recognized by all countries in the world. Insulating glass is a glass product that separates two or more pieces of glass evenly with effective support and bonds and seals around to form a dry gas space between glass layers. The main materials are glass, warm edge spacer, corner bolt, butyl rubber, polysulfide rubber and desiccant.

Features

① Great energy saving effect Due to a special metal film, the high-performance insulating glass can reach a shielding coefficient of 0.22-0.49, which can reduce the load of indoor air conditioning (cold air). The heat transfer coefficient is 1.4-2.8w (m2. K), which is better than ordinary insulating glass. It also plays a great role in reducing the indoor heating load. Therefore, the larger the window, the more obvious the energy saving effect. ② Improve indoor environment The high-performance insulating glass can intercept the considerable energy radiated into the room by the sun, thus preventing the discomfort caused by radiant heat and alleviating the glare caused by the sunset sun. ③ Rich colors and artistry High performance insulating glass has a variety of colors. You can choose colors according to your needs to achieve a better artistic effect. ④ Application of high performance insulating glass It is suitable for public facilities such as office buildings, exhibition rooms, libraries, and special buildings requiring constant temperature and humidity such as computer rooms, precision instrument workshops, chemical factories, etc. In addition, it can also be used for sunscreen and anti glare places.

Purpose

Insulating glass is mainly used in buildings that need heating, air conditioning, noise or condensation prevention and that need no direct sunlight and special light. It is widely used in houses, hotels, hotels, office buildings, schools, hospitals, shops and other places where indoor air conditioning is required. It can also be used for doors and windows of trains, cars, ships and freezers. [2] Insulating glass is mainly used for decoration of outer glass. Its optical performance, thermal conductivity and sound insulation coefficient shall meet the national standards. The insulating glass with reasonable structure and standard design can play its role of heat insulation, sound insulation, anti-theft and fire prevention. The vacuum double-layer toughened glass can reach the laboratory standard! There are also Insulating glass added with inert gas and color pigment gas in the market, as well as beautiful scenery strips to strengthen and decorate. Function of insulating glass aluminum spacer: aluminum is known as an active metal element, but a dense oxide film will be formed on its surface in the air, so that it cannot continue to interact with oxygen and water. It can react with oxygen at high temperature and release a large amount of heat. With this high reaction heat, aluminum can replace metal from other oxides (thermite method).

Specifications

Insulating glass is composed of two or more layers of flat glass. Two or more pieces of glass are bonded and sealed with sealing strips and glass strips with high-strength and high air tightness composite adhesive. The middle is filled with dry gas, and the frame is filled with desiccant to ensure the dryness of the air between the glass sheets. According to the requirements, glass original sheets with different properties can be selected, such as colorless transparent float glass embossed glass, heat absorbing glass, heat reflecting glass, wire glass, tempered glass, etc. and frame (aluminum frame or glass strip, etc.), which are made by bonding, welding or welding. The insulating glass can be 3, 4, 5, 6, 8, 10 and 12mm thick original sheet glass, and the air layer can be 6, 9 and 12mm thick.
